Meter – Moving Coil Milliammeter (Centre Zero)

A simple demonstration of a Dynamo Model mounted on a wooden base. Hand driven by a gear. Simplified open frame construction which can be readily understood without detriments to its essential similarity to real machine. A 2 pole armature wound by enamelled copper wire to rotate in U shape magnet in pivot. While in rotation process through the gear wheel by hand, the bulb provided glows.

Used for measurement of small quantities of electrical charge.

Levelling Screws for balancing the coil. Coil with mirror suspended between long suspension at the upper end and a spring at lower end. Suspension and spring are made of phosphor bronze alloy. Bakelite case, rigid and robust. Clamping arrangement for transportation. Consistent sensitivity over a large period. Strip provided for making it a periodic
