2-Stroke Diesel Engine
A model of two-stroke diesel engine made in aluminium alloy and gun metal.
Ignition is shown by means of a miniature bulb. Fuel supply is also sectioned. With hand crank, provided for manual operation. Mounted on base, with printed diagram showing working.
Related products
- Engines & Heat Physics Labware
Charles Law Apparatus
A glass U tube, 15 mm dia, with one limb plain 220 mm long and other limb graduated 25 to 35 x 0.2 ml, 120 mm long terminating in a bulb 38 mm diameter, with third limb 185 x 6 mm (L x D) joined at right angles to the plane of the other two, short length of glass tubing mounted in end of wide bore plain limb with rubber bung, a piece of rubber tube and a pinch clip..
Supplied with tall form beaker 1000 ml and stirrer. 30 ml mercury is required. Supplied without mercury and without thermometer.SKU: n/a - Engines & Heat Physics Labware
Sectional Model of Steam Engine
The engine model comprises a section cut metal cylinder covered with transparent acrylic plate to observe the working parts -piston, valves, link motion and reversing methods.
The movement of wheel is very light to demonstrate the working even by blowing through mouth. Mounted on a moulded metal base.
SKU: n/a - Engines & Heat Physics Labware
Ball and Ring Apparatus
GRAVESANDE – Ring and Ball with Chain. An apparatus for demonstrating thermal expansion, comprising a captive brass ball secured to a mounted brass ring by a chin, Ring mounted on rod with a wooden handle. The ball passes through the ring when cold but will not pass through after being heated
SKU: n/a - Engines & Heat Physics Labware
Ball and Ring Apparatus 2
GRAVESANDE – Ring and ball, mounted on separate handle ball.
An apparatus for demonstrating thermal expansion, comprising a captive brass ball secured to a mounted brass ring by a chin, Ring mounted on rod with a wooden handle. The ball passes through the ring when cold but will not pass through after being heated.
SKU: n/a
