Condenser Aepinus
Comprising two metal discs, with variable separation, supported on insulating pillars & provided with insulating handles on the ends of the adjustment slide rods, 4 mm sockets too are drilled onto the ends of the rods.
A rectangular glass plate is supplied which mounts in clips between the two discs & may be easily replaced by a plate of some other material to show the effect of different dielectrics. The whole is mounted on a polished wooden base.
Magnetic Field Apparatus
Apparatus To Show Force On Conductor In Magnetic Field – Comprising a strong U-shaped magnet and a pair of brass rails with 4mm socket terminals. A brass axle with plastic discs is free to roll along the rails and completes the electrical contact between them. When the axle is placed on the rails between the poles of the magnet, and a power supply unit is connected, the axle rolls along the rails, away from the centre of the magnetic field. Apparatus To Show Force On Conductor In Magnetic Field for Magnetism Experiment in Physics Lab.
Worchester Electromagnetic Kit
This kit is most versatile as it enable students to perform a wide range of experiments in electromagnetism such as construction of working motors and meters. It comprises eight anisotropic alloy magnets, eight anisotropic ceramic ferrite magnets, four steel magnet yokes, six plotting compasses, four hard board formers for compasses, one bottle iron fillings, four iron filling dispensers, four each double C-cores, clips for C-cores, aluminium rings, split aluminium rings, four each support bases, armature with axle tubes, aluminium axle rods, eight split pins, 16 rivets, one length latex rubber tubing, four each formers for coils, reels cellulose tape, reels copper wire, four each sheets white pasteboard, plain postcard, reels white cotton, four each C-resistors 100 ohm, 10 ohm, ten flash lamp bulbs, four neon bulbs, eight (MES) bulb holders, wood clamp, wood block.
Demountable Transformer
Demountable Transformer for Physics Lab Comprises U & I cores of low loss magnetic material, to form a closed core of cross section 25 mm in plane of laminations, 32 mm perpendicular to them is an I – core of length 102 mm. U core external height 102mm. Internal height to take bobbin length 77 mm. Pair of pole pieces, each 65x30x25 mm with on end shaped to part of a cone for maximum flux density. Hole drilled through total length along cone axis to take a light beam. Pole pieces will accept supertrods & shading ring (provided with accessories) & may be clamped on any separation on U core, or in contact as a non laminated I – core. Cast aluminium alloy stand consisting of a heavy base on four rubber feet with removable clamping arms. Maximum dimensions of base 190x200x115 mm. Channel 35 mm wide & 3 mm deep to take transformer core, extends across full width. Integral support for arms, to rear, is below the level of the pole pieces. Arms pivot on steel spindle with adjustment of knobs to rear bringing hard rubber pads at front end of arms to bear on transformer core. Synthetic hammer finish except of clean metal in channel & 4 mm hole to take on earthing plug lead. Complete with all the accessories
Shop
Showing 433–456 of 566 results
- Mechanics Physics Labware
Pendulum Compound
This pendulum is used to investigate the relationship between the period of oscillation of a rigid bar pendulum and the distance of its suspension point from its centre of mass.
It comprises a steel rectangular bar 1 meter long, drilled at 50 mm inervals. A removable steel knife edge, mounted perpendicularly, a wall bracket is provided for suspension.
SKU: n/a - Mechanics Physics Labware
Pendulum Simple Lead
Solid lead sphere with a small ring.
Dia (a) 13 mm (b) 19 mm (c) 25 mm
Pendulum Simple, Steel: PMCH-0050Brass sphere with a small ring for suspension.
Dia (a) 13 mm (b) 19 mm (c) 25 mm
Perspex Container: PMCH-0051
To demonstrate density made of plasticSKU: n/a - Magnetism Physics Labware
Plotting Mariner’s Compass
Plotting Mariner’s Compass for Physics Lab – Magnetic needle mounted in a circular dish, having printed scale at the inside of the bottom, fitted with glass on the top.
Diameter :
(a) 12mm
(b) 16mm
(c) 20mm
(d) 25 mm
(e) 38 mm
(f) 50 mm
(g) 75mmSKU: n/a - Electronics Lab Experiments
Power Supply (D.C) Regulated (Digital) 0-30V: Capacity: 10A
The DC Regulated Power Supply is an easy to use, low ripple high regulation precision instrument. Its unique feature is overload protection which makes it a safe power source for testing of electronic equipment.
Both voltage and current are precisely regulated with low output ripple. The power supply can be operated in either constant voltage or constant current mode and is protected against overload or short circuit by means of automatic cross-over characteristics from C.V. to C.C.
The output voltage and currents can be read on a meter. A switch is provided to select the LOW or HIGH’ range of current. Maximum voltage is 30 volts.
Specification
Indication of: 3 1/2 digital panel meter voltage/ currentor analog panel meter
Accuracy of DPM: 0.5% + 1 digit
Line Regulation: 0.05% plus 2 mv(for + 10% change in mains voltage)
Protection: Automatic cross-over type of output characteristic from C.V. to C.C.
SKU: n/a - Electronics Lab Experiments
Power Supply (D.C) Regulated (Digital) 0-30V: Capacity: 1A
The DC Regulated Power Supply is an easy to use, low ripple high regulation precision instrument. Its unique feature is overload protection which makes it a safe power source for testing of electronic equipment.
SKU: n/a - Electronics Lab Experiments
Power Supply (D.C) Regulated (Digital) 0-30V: Capacity: 2A
The DC Regulated Power Supply is an easy to use, low ripple high regulation precision instrument. Its unique feature is overload protection which makes it a safe power source for testing of electronic equipment..
Indication of: 3 1/2 digital panel meter voltage/ currentor analog panel meter
Accuracy of DPM: 0.5% + 1 digit
Line Regulation: 0.05% plus 2 mv(for + 10% change in mains voltage)
Protection: Automatic cross-over type of output characteristic from C.V. to C.C.
Power Source: 220 V AC + 10% / 50Hz.SKU: n/a - Electronics Lab Experiments
Power Supply (D.C) Regulated (Digital) 0-30V: Capacity: 5A
The DC Regulated Power Supply is an easy to use, low ripple high regulation precision instrument. Its unique feature is overload protection which makes it a safe power source for testing of electronic equipment..
Indication of: 3 1/2 digital panel meter voltage/ currentor analog panel meterAccuracy of DPM: 0.5% + 1 digit
Line Regulation: 0.05% plus 2 mv(for + 10% change in mains voltage)
Protection: Automatic cross-over type of output characteristic from C.V. to C.C.
Power Source: 220 V AC + 10% / 50Hz.
SKU: n/a - Electronics Lab Experiments
Power Supply 5 KV E.T.H.
Output 100 to 5 KV at 3 mA continuous. Fully floating EHT circuits suitable for operation of spart, counters, discharge tubes etc. Provided variable output upto 5 KV. The EHT circuit are fully floating so that certain experiments the positive or negative terminals may be safely connected to earth..
The EHT output are taken from 4mm sockets and displayed on a 0 to 5 KV meter. Also on the front panel are a mains switch and indicator lamp. The main fuse is mounted on the back panel. In a robust metal case with feet, mains cable fitted by moulded connector. Cable and connector removable for storage. Workable on 220V 50 Hz.
SKU: n/a - Electronics Lab Experiments
Power Supply A.C/D.C Low Tention
0-20 volts D.C. And 0-25 volts A.C. continuously variable at 10/5/2 Amps. With dual meter to read volts AC/DC.
Output is provided at 4 mm socket terminals separate for A.C. and D.C. ON/OFF switch, indicator and two output safety fuse.
SKU: n/a - Electronics Lab Experiments
Power Supply A.C/D.C Low Voltage
Details for Power Supply A.C/D.C Low Voltage for Physics Lab
2 to 12 volts in step of 2 volts.
.
Four 4mm socket terminals for AC and DC output separately with fuse and indicator in ventilated painted steel cabinet.
a) 4 Amp.
b) 5 Amp.SKU: n/a
