Meter – Dual Scale Voltmeter

Each centre hole coil is wound on a plastic former & is provided with 4 mm socketed terminals.

The coil fits onto a double ‘C’ core, provides a suitable transformer for operation from a low voltage AC supply. In addition, it provides a useful electromagnet if used on one half of a ‘C’ core.

A simple demonstration of a Dynamo Model mounted on a wooden base. Hand driven by a gear. Simplified open frame construction which can be readily understood without detriments to its essential similarity to real machine. A 2 pole armature wound by enamelled copper wire to rotate in U shape magnet in pivot. While in rotation process through the gear wheel by hand, the bulb provided glows.
