Insulated, PVC coated, with one end crocodile clip and at the other end banana plug
Your RatingRate…PerfectGoodAverageNot that badVery Poor
Your Review
Name *
Email *
There are no reviews yet.
4 DIAL: Multiplier – x 0.001, x0.01, x0.01, x1 mtd. Polyster capacitor, accuracy 3%
Also available in: 1 DIAL 2 DIAL 3 DIAL 6 DIAL
Laminated core to form a roughly rectangular core 92 x 56 x 20 mm approx. With a cross section of 20 x 12 mm & is cut across the middle to produce 2 equal āCās. A strong spring steel strip is provided to hold the two halves together.
A contact arm & three metal studs mounted on a bakelite base with three brass terminals. The centre terminal is common connection to the arm & the other two terminals connected to the other studs.
Used in charging & discharging of a capacitor. C.P. brass strips & pillars. Three terminals fitted on a thick bakelite plate of high insulation. Contact resistance 2 milliohms approx. Maximum current 5 amps. Dimensions : 185 x 15 x 45 mm.
