Convection Tube

GRAVESANDE – Ring and Ball with Chain. An apparatus for demonstrating thermal expansion, comprising a captive brass ball secured to a mounted brass ring by a chin, Ring mounted on rod with a wooden handle. The ball passes through the ring when cold but will not pass through after being heated

Heavy cast iron base with 4 uprights, on one end of which is fitted a hand nut, the other drilled with holes to carry a cast iron rod bearing against narrow flats with 12 cast iron breaking rods to show force of contraction or expansion
