Physics Lab
Showing 121–144 of 383 results
- Electrostatic Physics Labware, Physics Lab
Electrostatics Kit
A comprehensive kit of apparatus to enable students to investigate many aspects of electrostatic forces.
The kit comprises of : 1 Electroscope, 1 Rubber (polishing cloth), 4 metalled polystyrene spheres, 1 plated wire hook, 1 reel nylon monofilament, 1 Electrophorous plate on insulating handle, 1 cellulose acetate strip, 1 polythene strip, 1 proof plane on insulating handle, 1 wire stirrup to support the above two items, 2 polythene tiles & 2 aluminium cans.
SKU: n/a - Engines & Heat Physics Labware
Expansion Apparatus
It comprises two cast iron uprights vertical pillars height approx 180 mm linked by rods, supporting an expansion bar, length 380 mm, fixed to one upright and resting on a friction pointer at the other with scale, supplied with one each aluminium; iron and brass expansion bars.
SKU: n/a - Engines & Heat Physics Labware
Expansion Apparatus Gunter
Comprising two cast end pieces, joined by three nickel-plated rods, caring two sliding V-supports for a glass jacket with inlet and outlet tubes.
One end-piece fitted with spherometer reading to 0.005 mm, and the other with contact screw.
The glass jacket enclosed both a brass and a copper rod each 500 x 7 mm length x diameter, fitted through corks , a half turn of the jacket changing rod in contact with the spherometer.
A thermometer can be attached to be either of the rods by rubber bands. Brass terminals are fitted to the apparatus so that an electrical circuit can be made through either rods, to indicate the moment of contact of centre tube and spherometer.
Supplied with 3 metal rods one each of copper, brass and iron.SKU: n/a - Engines & Heat Physics Labware
Expansion Apparatus Linear
Used to determine the coefficient of expansion of different metals.
The rod to be tested is placed inside a tube that has both an inlet and outlet for steam. A thermometer monitors temperature change. A bell or galvanometer is used to gauge the exact point of contact of the micrometer for precise measurement. Provided with 3 Rods–Iron, Copper and Brass.
SKU: n/a - Engines & Heat Physics Labware
Expansion of Liquids Apparatus
To show difference in expansion of various liquids over the same temperature range.
It comprises 5 glass graduated capillary tubes of equal bore and bulbs at the bottom, mounted on a support frame with metal trough for immersion of bulbs in hot water in it.SKU: n/a - Optics Physics Labware
Eye Model Functional
A unique apparatus that allows you to recreate the conditions of visual deficiencies in the human eye..
Consists of clear silicone elastic lens chamber, filled with water
When water is added or removed with the included syringe, the curvature of the lens is changed, which alters the focus of images projected on the retina
Adjustable eyeball shape
Lenses can be added to show how vision defects can be corrected
Five-piece model mounted on a base with the projection object on a separate stand
Supplied complete with two lenses, lens holder and instruction manualSKU: n/a - Mechanics Physics Labware
Flectchers Trolley
Comprises a lightweight aluminum track with leveling screws and cushioned stops at either end, pulley fixed towards one end, clamp for vibrator and automatic pen release.
A metal trolley with ball bearing mounted wheels to minimize friction, has five holes for accommodating cylindrical masses, including is a vibrator and pen holder with one each wooden blocks, to demonstrate the experiments on acceleration.SKU: n/a - Fluid Mechanics Physics Equipments
Fluid Pressure Apparatus
To demonstrate the transmissibility of fluid pressure. The apparatus comprises two metal cylinders 15 mm and 30 mm dia respectively fitted with piston and connected by a tube. The pistons are provided with rods terminating in plate forms for loading with masses required. The complete apparatus is fitted on a wooden base.
SKU: n/a - Magnetism Physics Labware
Force on a conductor balance
Force on a conductor balance – It is used to demonstrate that when a current is passed through a conductor in a magnetic field, it is subjected to a force of attraction or repulsion depending upon the direction of current in it. It consists of a plastic base 160 x 140mm on which two contact pillars are mounted. Each pillar is provided with an external circuit. A balance beam is supported by the pillars on two bearings, which form the fulcrum. Two screwed masses are provided in the beam system, one moving vertically for the adjustment of sensitivity and the other moving horizontally for the adjustment of the equilibrium position, when no current is flowing. Scale marked 0 to 75 x 1mm, rider of 1 gm weight.
SKU: n/a - Fluid Mechanics Physics Equipments
Force Pump
A working model to demonstrate the principles involved in the action of a force-pump.
Cylinder is 25 x 350 mm dia x overall height. It is provided with a non-return float valve at its lower end. Lower part of the cylinder has an outlet side tube communicating with the lower end of another cylinder also equipped with non-return valve. Outlet tube from the secondary cylinder is drawn out into a jet to demonstrate ability of force pump to eject water at high pressure.
SKU: n/a - Mechanics Physics Labware
Force Table
To verify the law of composition and resolution of forces.
This consists of machined aluminium table 40 cm. in diameter. Its raised rim has a scale, graduated in 360 degree, mounted on vertical support rod based provided with levelling screws. Body under study is a ring in center of the table fastened by cords passing over four pulleys, attached with the table.
Complete with four pulleys, four weight hangers, twelve weights 2 x 10 gm. 2 x 20 gm. 4 x 50 gm. 4 x 100 gm.
SKU: n/a - Mechanics Physics Labware
Forces Apparatus
To verify the relationship between forces action at a point. Comprises board 65 x 50cm, with two aluminium pulleys, 50mm dia, on clamp, for mounting in any position..
Complete with three hangers iron nickel-plated 50gm and 12 slotted weights of 50gm each, supplied with reel of cotton thread and a ring.SKU: n/a
