Electrostatic Physics Labware
Showing 1–24 of 35 results
- Electrostatic Physics Labware, Physics Lab
Condenser Aepinus
Comprising two metal discs, with variable separation, supported on insulating pillars & provided with insulating handles on the ends of the adjustment slide rods, 4 mm sockets too are drilled onto the ends of the rods.
A rectangular glass plate is supplied which mounts in clips between the two discs & may be easily replaced by a plate of some other material to show the effect of different dielectrics. The whole is mounted on a polished wooden base.SKU: n/a - Electrostatic Physics Labware, Physics Lab
Dynamo Bicycle
A cycle dynamo mounted on a wooden base 200 x 115 x 12 mm & provided with two sets of gears driven by a hand crank for fast or slow rotation. Two 4 mm socket terminals are provided for the dynamo output. Connected in parallel with an MES lamp holder & 2.5 V bulb.
SKU: n/a - Electrostatic Physics Labware, Physics Lab
Electric Fields Apparatus
Comprises a shallow glass dish 100 x 10 mm & a pair of socket terminals/ electrode holders that clip onto its rim. A compliments of six electrodes is supplied, two point source, two line source & two circular rings of 70 & 35 mm diameter respectively
SKU: n/a - Electrostatic Physics Labware, Physics Lab
Electric Whirl
For demonstrating the effect of electric discharge from points.
The apparatus has 60 mm diameter six pointed star wheel with all the points curved in one direction. The wheel rotates freely on a pivot point mounted on a short stand & the stand is provided with a 4 mm connection socket on the round base.
SKU: n/a - Electrostatic Physics Labware, Physics Lab
Electroscope – Gold Leaf
Rectangular casted metal case and polythene insulated lid with finger flap to facilitate removal.
Fitted with 4 mm. socket. Front glass window slides up to allow insertion of ionizing material in chamber, gold leaf support plate and scale to show deflection, with one pair of leaves.
SKU: n/a - Electrostatic Physics Labware, Physics Lab
Electrostatics Kit
A comprehensive kit of apparatus to enable students to investigate many aspects of electrostatic forces.
The kit comprises of : 1 Electroscope, 1 Rubber (polishing cloth), 4 metalled polystyrene spheres, 1 plated wire hook, 1 reel nylon monofilament, 1 Electrophorous plate on insulating handle, 1 cellulose acetate strip, 1 polythene strip, 1 proof plane on insulating handle, 1 wire stirrup to support the above two items, 2 polythene tiles & 2 aluminium cans.
SKU: n/a
